Premium Maxon 2607 Coreless DC Motor China Manufacturer

Welcome to www.coreless-motor.com. As a leader in advanced micro-drive solutions, we proudly present our high-performance 2607 Coreless DC Motor. Engineered for applications demanding compact footprints, high efficiency, and rapid dynamic response, this motor sets the benchmark for ultra-slim and micro-cylindrical motion technology.

What is a 2607 Coreless Motor?

The 2607 Coreless Motor is a specialized micro direct-current motor featuring a unique ironless rotor architecture. The nomenclature designates an outer diameter of approximately 26 mm and a thickness/length of around 7 mm (typically configured as an ultra-slim, flat-type profile).

Unlike traditional motors with iron cores, coreless designs eliminate magnetic core losses, providing exceptional miniaturization and energy efficiency.

Key Advantages & Features

High Efficiency & Low Energy Consumption: Free from iron-core hysteresis and eddy current losses, energy conversion efficiency routinely reaches 70% to 90%+.
Rapid Response & Dynamic Performance: Extremely low rotor inertia ensures millisecond-level startup and braking times.
Zero Cogging Effect: The ironless rotor guarantees ultra-smooth rotation completely devoid of traditional cogging or stumbling at low speeds.
Minimal Electromagnetic Interference: Premium commutation systems reduce electrical sparking and acoustic/electromagnetic noise.

Technical Specifications & Electrical Performance (12V Reference Example)

Specifications can vary depending on custom winding designs (compatible with standard industry standards like Faulhaber, Maxon, or XH Motor). Below are the benchmark specifications for a standard 12V flat-type 2607 coreless motor:

1. Mechanical & Physical Dimensions

Dimensions (Diameter × Length): 26 mm × 7 mm (Ultra-slim flat design)
Shaft Diameter: Standard 1.5 mm
Weight: Approx. 15g – 20g (Depending on housing and bearing configurations)
Rotor Structure: Ironless honeycomb cup rotor (Low inertia, cog-free)
Commutation System: High-grade precious metal brushes and commutator (Long operational life)

2. Electrical Performance Parameters

Performance Indicator	Typical Range	Description
Rated Voltage	6V ~ 24V (Most common: 12V)	Standard operational design voltage
No-load Speed	7,000 ~ 11,500 RPM	Rotational speed without applied load
No-load Current	15 ~ 25 mA	Ultra-low standby draw highlighting high efficiency
Rated Speed	5,500 ~ 9,200 RPM	Recommended operating speed under nominal load
Rated Torque	1.0 ~ 3.5 mNm (Approx. 10~15 g·cm)	Continuous, stable output force
Rated Current	80 ~ 140 mA	Current consumption under standard operating conditions
Stall Torque	50 ~ 110 g·cm (Approx. 5~11 mNm)	Maximum instantaneous force at complete rotor lock
Stall Current	0.3 ~ 0.9 A	Maximum peak current (allow driver overhead headroom)

Export to Sheets

3. Dynamic & Control Characteristics

Mechanical Time Constant: Superior speed response within the 6ms to 8ms range for instant start-stop execution.
Rotor Inertia: Extremely low (approximately 0.7 g⋅cm2), eliminating lag during rapid directional shifts.
Back-EMF Constant: Varies by voltage winding (e.g., ~0.9 mV/RPM for 6V; ~3.8 mV/RPM for 24V), ideal for closed-loop precision speed tracking.
Terminal Resistance: Ranges from single digits (e.g., ~8 Ω for 6V variants) up to over 100 Ω for higher-voltage models.

Target Application Fields

Because the 2607 motor combines ultra-low profiles with heavy-duty torque density, it drives cutting-edge portable and handheld technologies:

Tattoo Pens & Machines: 2607 and 2610 flat coreless motors serve as the powerhouse core for professional rotary tattoo devices, offering low-vibration, high-endurance performance.
Precision Medical & Beauty Equipment: Integrated into micro-infusion pumps, fluidic devices, and high-frequency cleansing instruments.
Smart Hardware & Micro-Gimbals: Tailored for ultra-compact servomechanisms, camera stabilization units, and micro-actuators.

Looking for customized winding options, voltage adjustments, or bulk technical data sheets for your engineering project? Visit us at www.coreless-motor.com to request a custom quote or consult with our motor design experts today!
